Regular price$1,699.00
/
Color
  • FREE LOCAL DELIVERY
  • Low stock - 10 items left
  • Inventory on the way

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Two motor e-bike with one throttle

There is a 250w front-geared motor, and a 350w rear-geared motor. In many states, it is legally classified as an electric bicycle, as the vehicle doesn’t exceed a total of 750w of power.

The system is operated by a single battery that locks into position, a single controller, and a single set of controls that are at the front. To operate the system is simple: on the right side of the handlebars is a red rocker switch where you get to choose which motors to operate. The throttle and pedal assist function like any other - driving the wheels depending on the position of the rocker switch. With the switch positioned in the middle - both motors will be functioning. When turned to the left, only the front motor will be switched on, and when turned right—the rear motor.

Motor Selector Switch

Turn the switch to the left to get the front motor to start; turn it to the right to get the rear motor going. When the switch is in the middle, you’ll hear the monster dual motors roar!

350W Rear-Mounted Motor

A hub motor in the rear wheel can crank out a continuous 350W watts of power with the ability to ratchet things up to over 500 peak watts of power for hill climbs and quicker acceleration. This motor has 60 Newton meters of torque.

Shimano 7 Speed Gear Shift System

With this Shimano 7 speed freewheel, there is a larger cog for up-hill riding and a smaller cog for high-speed riding. Speed can be easily adjusted with the pedal-assist system.

SPECIFICATIONS

Battery:48V/15.6Ah

Range:35+Miles With A single Wheel

Motor:48V/250W+350W Geared hub motor

Total Payload Capacity:380 lbs

Recommended Rider Heights:5'3" ~ 6'1"

Maximum Speed:20MPH

Charger:US standard 2.0 A smart charger

Controller:48V / 15A * 2

Display:DZ29 display

Weight:62lbs

Pedal Assist Intelligent:0~5 level pedal assist

Box Dimensions:(cm) 173 L x 30 W x 82 H

COMPONENTS

Tires:Kenda Krusade Sport Tires 26 x 4.0

Brake lever:Promax Disc Brakes Lever with motor cutoff switch

Rear Light:Taillight

Shifter:Shimano 7 speed gear shift system

Brake Rotor:Promax 160MM Disc Brakes

Throttle:Thumb Throttle

Crank:170mm forged alloy

Freewheel:Shimano 14-28T

Handlebar:Mid-Rise, Aluminum Alloy, 650mm Length

Frame Material:Aluminum Alloy 26*17.5inch

Stem:Aluminum Alloy Promax MA-400

Pedal:Wellgo Aluminum Alloy Platform with Reflectors

Front Light:Integrated LED light

Saddle:Velo Plush

Tool:Included

Chainring:46T chain-wheel crank

Rims:26 inch Black Alloy

Seat Post:Promax, Aluminum Alloy
